Blackmagic Design ATEM Television Studio Pro HD

ATEM Television Studio Pro HD combines a professional broadcast hardware control panel with a powerful 8 input switcher. It includes 4 SDI and 4 HDMI inputs, all with re-sync, so customers can connect a total of up to 8 different sources such as professional SDI broadcast cameras, consumer HDMI cameras, computers and even video game consoles.

ATEM Television Studio Pro HD is compatible with all SD and HD formats up to 1080p60 and also features two channels of analog audio in, RS-422, Ethernet and a built in IEC power supply, along with program and auxiliary outputs. Customers also get both SDI and HDMI multiview outputs so they can monitor all sources, preview and program outputs, along with labels, audio meters and more, all on a single big screen television or broadcast monitor.

Featuring a portable design, ATEM Television Studio Pro HD is packed with high end broadcast features that make it possible to create an entire live switched program, complete with effects and transitions. The hardware panel features large illuminated buttons for switching between sources, along with corresponding audio buttons, one touch transition buttons, downstream keyers, fade to black, media player, cut buttons and more. There's also a built in LCD screen for previewing source and program video, a spin knob and additional buttons for menus and to adjust settings. Customers simply press the button for the source that they want to see next in the program, then hit the cut or auto button to switch sources, add effects, or even key in graphics.

When used with Blackmagic Studio and URSA Mini cameras, customers get a complete remote control solution that includes talkback, tally, color correction, camera control and more, without having to add any additional cables or proprietary control boxes. These cameras feature a built in color corrector that can be remote controlled, making it possible to balance camera color and create unique looks, all from the control panel. In addition, customers can adjust focus and iris on compatible lenses, change camera settings, and even remote control PTZ heads.

ATEM Television Studio Pro HD also includes a built in talkback converter for SDI cameras. The talkback information is sent back to the camera via the SDI program return feed on the rarely used SDI audio channels 15 and 16. When working live with a reporter in the field, there can be a slight delay that causes them to hear themselves as an echo in their headset. ATEM Television Studio Pro HD includes a new mix minus feature that sends back all the program audio except their own voice, so they don't hear a distracting echo of themselves while reporting.
