Seetec WPC215 Broadcast Monitor
by SeetecThe 21.5" 4K Broadcast Carry-On Director Monitor from Seetec features a maximum resolution of 1920 x 1080 and 1000 cd/m² brightness for viewing in any lighting conditions.
- Ratenzahlung Sie können auf Raten mit den Visa, Visa Premium, Maestro, Master Card und Diners reditkarten zahlen. Die Gebühr beträgt 5% des offengelegenen Preises und wird im Warenkorb bei der Zahlungsauswahl gerechnet. Sie können mehr Details auf dem Link Zahlungsarten überprüfen.
- Schnelle Lieferung Für alle Lieferungen innerhalb Kroatiens, die bis 14.00 Uhr erhaltet werden, wird die Lieferung binnen einem Arbeitstag geliefert. Für die ganze Europa nehmen wir die schnelle Zustellung vor und mehr Details können Sie auf dem Link Lieferungsarten überprüfen.
- Internationaler Kauf Die EU-Firmen (außer die Republik Kroatien) zahlen den Preis ohne die Mehrwertsteuer mit dem gültigen VAT ID- Nummer. Der Preis wird bei Check-Out gerechnet. Alle Käufer außerhalb der Europäischen Union zahlen den Ausfuhrpreis ohne die Mehrwertsteuer.
Paket beinhaltet
- WPC215 Broadcast Monitor
- Power Adapter
- V-Mount Battery Plate
- Mini HDMI Cable
- SDI Cable
The 21.5" 4K Broadcast Carry-On Director Monitor from Seetec features a maximum resolution of 1920 x 1080 and 1000 cd/m² brightness for viewing in any lighting conditions. The rear contains one 3G-SDI input and output and two HDMI inputs and outputs. The HDMI input supports up to DCI 4K video The monitor is installed in a carry-on protective case, and it can be carried using a handle on top.
Professional monitoring tools such as waveform, histogram, focus assist, monochrome, and more are built-in for analyzing your video and ensuring a proper image. A V-mount battery plate is built into the back for powering in the field when you are away from a mains source.
| Display | |
| Panel Type | IPS-Type LCD |
| Display Size | 21.5" / 54.6 cm |
| Resolution | 1920 x 1080 |
| Aspect Ratio | 16:9 |
| Viewing Angle | Horizontal: 178° (89/89) |
| Vertical: 178° (89/89) | |
| Touchscreen | No |
| Maximum Brightness | 1000 nits / cd/m2 |
| Contrast Ratio | 1000:1 |
| Dot Pitch | 0.02479 x 0.02479 mm |
| HDR Compatibility | None |
| Pixels Per Inch (ppi) | 102 ppi |
| Response Time | 25 ms |
| Image Controls | Anamorphic De-Squeeze, Blue Only, Check Field, False Color, Focus Assist, Focus Peaking, Green Only, Image Rotate, Red Only, Screen Markers, Screen Split - Half, Screen Split - Quarter |
| Inputs / Outputs | |
| Video I/O | 2 x HDMI Input |
| 1 x BNC (3G-SDI) Input | |
| 2 x HDMI Output | |
| 1 x BNC (3G-SDI) Output | |
| Embedded Audio | HDMI/SDI |
| Audio I/O | 1 x 1/8" / 3.5 mm Headphone Output |
| Built-In Speaker | 1 |
| Power I/O | 1 x Barrel (12 VDC) Input |
| Other I/O | 1 x USB-A 2.0 Input |
| Media/Memory Card Slot | None |
| Wi-Fi | None |
| Bluetooth | None |
| Mobile App Compatible | *As of April, 2023: Check with manufacturer for the most up-to-date compatibility |
| Format Support | |
| Video Format | HDMI |
| DCI 4K: 24 | |
| UHD 4K: 30/29.97/25/24/23.98 | |
| 1080p: 60/59.94/50/30/29.97/25/24/23.98 | |
| 1080i: 60/59.94/50 | |
| 720p: 60/59.94/50/30/29.97/25/24/23.98 | |
| 576p | |
| 576i | |
| 480p | |
| 480i | |
| SDI (8-Bit) | |
| 1080p: 60/59.94/50/30/29.97/25/24/23.98 | |
| 1080i: 60/59.94/50 | |
| 1080PsF: 24/23.98 | |
| 720p: 60/59.94/50/30/29.97/25/24/23.98 | |
| Gamma Curve | Rec709 |
| Power | |
| DC Input Power | 12 VDC |
| Battery Type | 1 x V-Mount |
| Power Consumption | 32 W |
| Environmental | |
| Environmental Protection | Advertised as Dust Resistant/Moisture Resistant/Outdoor Use/Water Resistant/Weather Resistant with Included Housing |
| *Manufacturer Testing: IP67 | |
| Operating Temperature | 32 to 122°F / 0 to 50°C |
| Storage Temperature | -4 to 140°F / -20 to 60°C |
| General | |
| Material of Construction | Polycarbonate |
| Dimensions | 14.6 x 10.3 x 1.1" / 372 x 262 x 28.4 mm, Excluding |
| Weight | 32.6 lb / 14.8 kg |
