Sennheiser MKH 8020

by Sennheiser
Verfügbarkeit: 7-10 days delivery

Outstanding omni-directional instrument microphone. Ideal as a main mic for “spaced pair” and “Decca Tree” recordings or the use in an OSS “Jecklin Disk“ array. Wide frequency response: 10 – 60,000 Hz.

1.311,25 € 1.049,00 €

Paket beinhaltet

  • Microphone head MKHC 8020
  • XLR module MZX 8000
  • Microphone clip MZQ 8000
  • Windshield MZW 8000
  • User manual
  • Aluminium transport caser

The omni-directional MKH 8020 is ideal for recording large and small sound sources, for a "Decca Tree" or for use in an OSS "Jecklin Disk" array. As it does not suffer from a proximity effect, it is also a good choice for close-miking. If the acoustic ambiance is right, this microphone will provide very impressive recordings. The extra octave at the bottom end makes the MKH 8020 perfect for recording pipe organs, grand piano and acoustic double-bass.


  • Onmi-directional pick-up pattern

  • Modular design

  • Wide frequency response 10 to 60.000 Hz

  • Symmetrical transducer with 2 backplates providing extremly low distortion

  • Extremly low inherent self-noise

  • Accurate directional pattern

  • Non reflective Nextel coating

  • Ideal for stereo and surround recordings, as an M microphone and for ambience

  • Also available in stereo pairs

Analog Performance
Polar Pattern Omnidirectional
Frequency Range 10 Hz to 60 kHz
Equivalent Noise Level 10 dB A-Weighted
21 dB CCIR
Maximum SPL 138 dB SPL
Impedance 25 Ohms
Load Impedance 1000 Ohms
Output Connectors 1 x 3-Pin XLR
Operating Current Consumption 3.3 mA
Operating Voltage 48 V ± 4 V
Operating Temperature 14.00 to 140.00°F / -10 to 60°C
Length 2.95" / 75 mm
Diameter 0.75" / 19 mm
Weight 1.94 oz / 55 g
