SOMMER CABLE video cable SC-Vector Plus 1 x 1,20/5,0, green

by Sommer Cable
Raspoloživost: Dostupno
SKU
600-0174

Video cable SC-Vector Plus; 1 x 1,20; PVC Ø 6,95 mm; green

18,50 kn 14,80 kn

All the way to the horizon

and then some more. This is the transmission range of the SC-Vector Plus 1.2/5.0, because with its special dimensions and construction it has been designed for long distance HD-SDI applications. Even as an analogue cable it is already pretty amazing: you can transmit video signals over distances of up to 1000 m and as an SDI cable it can be used for distances of up to 600 m. The SC-Vector Plus 1.2/5.0 has an excellent shielding 100 % made of a tinned copper mesh plus AL/PT foil. The cable is very flexible and also suitable for mobile use on a cable reel. It is available in a single coax or a 5 x coax version with a PVC and FRNC jacket (according to test type C, IEC60332.3c). With HD-SDI the transmission range depends on the bitrate used (compressed or uncompressed). At 1.485 Gb/s (uncompressed) the damping value is drawn on at half the bitrate (720 MHz). The achievable cable length at a damping value <30 dB is considered as a relevant parameter.

Advantages:

  • Superb damping values for long distances of up to 1000 m
  • Robust and durable outer jacket, reelable

Application:

  • Digital HD/SDI long distance transmission
  • Cabling for sporting events and big TV events; OB van technology
Name SC-Vector Plus
Properties Digital 75 Ω
Properties OFC oxygen free copper
Properties Analog
Properties SDI
Application area ELA 100 V
Application area Installation
Application area Studio / Broadcast
Application area Mobile outdoor / indoor
Application video cable
Colour green
Colour detailed green
Construction 1x02YS(ST)CH1,2/5,0
Jacket material PVC
Jacket Ø [mm] 6,95
Number of Channels (video) 1
Inner conductor (video) 1
Inner conductor (video) [mm²] 0,88
Inner conductor Ø (video) [mm] 1,20
AWG (video) 18
Shielding AL / PT-foil + copper braiding 80 % tin-plated
Copper strands (video) 7
Copper strand Ø (video) [mm] 0,40
Conductor insulation material Foam / Skin-PE
Conductor insulation Ø [mm] 5,00
Weight per 1 m [g] 55
Fire load per m [kWh] 0,2
Style variant round
Shielding factor [%] 100
Packing bulk stock
Velocity factor 0,8
Temperature min. [°C] -10
Temperature max. [°C] 80
Max. Transmission length (3G-SDI) [m] 200
Max. Transmission length (6G-SDI) [m] 80
Width [mm] 7
Height [mm] 7
Capacity wire/electic screen at 1m (video) [pF] 52
Capacity wire/electic screen at 1 ft. (video) [pF] 15,8496
Damping at 5 MHz (100m & 20° C) [dB] 6,6
Damping at 5 MHz (100 ft. & 20 °C / 68 °F) [dB] 2,0117
Damping at 50 MHz (100m & 20° C) [dB] 7,2
Damping at 50 MHz (100 ft. & 20 °C / 68 °F) [dB] 2,1946
Damping at 100 MHz (100m & 20° C) [dB] 7,9
Damping at 100 MHz (100 ft. & 20 °C / 68 °F) [dB] 2,4079
Damping at 200 MHz (100m & 20° C) [dB] 9,3
Damping at 200 MHz (100 ft. & 20 °C / 68 °F) [dB] 2,8346
Damping at 470 MHz (100m & 20° C) [dB] 12,9
Damping at 470 MHz (100 ft. & 20 °C / 68 °F) [dB] 3,9319
Damping at 862 MHz (100m & 20° C) [dB] 17,8
Damping at 862 MHz (100 ft. & 20 °C / 68 °F) [dB] 5,4254
Damping at 1000 MHz (100m & 20° C) [dB] 19,4
Damping at 1000 MHz (100 ft. & 20 °C / 68 °F) [dB] 5,9131
Damping at 1485 MHz (100m & 20° C) [dB] 24,5
Damping at 1485 MHz (100 ft. & 20 °C / 68 °F) [dB] 7,4676
Damping at 1750 MHz (100m & 20° C) [dB] 27,1
Damping at 1750 MHz (100 ft. & 20 °C / 68 °F) [dB] 8,2601
Damping at 2150 MHz (100m & 20° C) [dB] 30,4
Damping at 2150 MHz (100 ft. & 20 °C / 68 °F) [dB] 9,2659
Damping at 3000 MHz (100m & 20° C) [dB] 35,9
Damping at 3000 MHz (100 ft. & 20 °C / 68 °F) [dB] 10,9423
Impedance [Ω] 75
Conductor resistance per 1 km [Ω] 21
Conductor resistance per 1000 ft. [Ω] 6,4008
Shield. resistance per 1 km [Ω] 11
Shield. resistance per 1000 ft. [Ω] 3,3528
EAN 4049371001403
