Tilta Tiltaing Sony a7/a9 Series Kit B - Tilta Gray
by Tilta- Formfitting Cage
- 1/4"-20 Accessory Mounting Holes
- 3 x Cold Shoes for Mounting Accessories
- Ratenzahlung Sie können auf Raten mit den Visa, Visa Premium, Maestro, Master Card und Diners reditkarten zahlen. Die Gebühr beträgt 5% des offengelegenen Preises und wird im Warenkorb bei der Zahlungsauswahl gerechnet. Sie können mehr Details auf dem Link Zahlungsarten überprüfen.
- Schnelle Lieferung Für alle Lieferungen innerhalb Kroatiens, die bis 14.00 Uhr erhaltet werden, wird die Lieferung binnen einem Arbeitstag geliefert. Für die ganze Europa nehmen wir die schnelle Zustellung vor und mehr Details können Sie auf dem Link Lieferungsarten überprüfen.
- Internationaler Kauf Die EU-Firmen (außer die Republik Kroatien) zahlen den Preis ohne die Mehrwertsteuer mit dem gültigen VAT ID- Nummer. Der Preis wird bei Check-Out gerechnet. Alle Käufer außerhalb der Europäischen Union zahlen den Ausfuhrpreis ohne die Mehrwertsteuer.
Paket beinhaltet
- Tilta Full Camera Cage for Sony a7/a9 Series (Tilta Gray)
- Tiltaing Hand Strap for Sony a7 and a9 Camera Cage
- Tilta Bottom Plate for Sony a7/a7S (Tilta Gray)
- Tilta Bottom Plate for Sony a7S II/a7R II/a7R III (Tilta Gray)
- Tilta Quick Release Top Handle for BMPCC 4K Cage (Tilta Gray)
- Cage Screw with Spring
- Rod-Locking Screw
- Tilta HDMI Cable Clamp Attachment for Sony a7 and a9 Cage (Tilta Gray)
- 2 x Screw
- Thumbscrew
- Tilta HDMI-01-M HDMI to Micro-HDMI Adapter
- Tiltaing Side Focus Handle Type III (NP-F570, Tilta Gray)
- Tiltaing Manfrotto Quick Release Plate
- Tiltaing Arca Quick Release Plate
This camera cage provides complete protective armor for the Sony a7, a7 II, a7 III, a7S, a7S II, a7R, a7R II, a7R III, and a9 cameras.
It provides several 1/4”-20 and 3/8”-16 mounting points as well as two cold shoe mounting points.
The base of the cage also provides several mounting holes when attaching your camera to gimbals to more easily fine tune the balance of your setup.
A variety of different baseplates can be attached to the bottom of the cage, allowing for various rod mounting and optional power supply configurations.
The quick release top handle and various optional side handles can be attached to the cage to provide for different ways to comfortably operate your camera setup.
This kit of the Sony a7/a9 cage includes: the base Sony a7/a9 cage, quick release top handle, Tilta Hand Strap, Arca and Manfrotto quick release baseplates, two different bottom plates depending on the camera you are mounting into the cage, an HDMI to Micro HDMI adapter, a clamp to attach the HDMI adapter comfortably to the cage, and finally the Tiltaing Side Power Handle Type III (F570 Battery).
** Note that this version of the Full Camera Cage for Sony a7/a9 Series is no longer being manufactured and that a new version is coming soon that will be compatible with the Sony a7R IV
Tilta Full Camera Cage For Sony A7/A9 Series (Tilta Gray) Specs
Mounting
|
Accessory Mounting |
Multiple x 1/4"-20 Thread |
|
Camera Mounting |
1/4"-20 Screw |
|
Shoe Mounting |
Top: 2 x Cold Shoe |
|
Rosettes |
None |
General
|
Support Type |
Cage |
|
Grip Type |
None |
|
Camera Compatibility |
Sony a7, Sony a7 II, Sony a7R, Sony a7R II, Sony a7R III, Sony a7S, Sony a7S II, Sony a9 |
|
Materials |
Aluminum, Steel |
|
Dimensions |
5.75 x 4.5 x 2.88" / 14.61 x 11.43 x 7.3 cm |
|
Weight |
0.58 lb / 0.26 kg (without Hand Strap) |
Packaging Info
|
Package Weight |
1.07 lb |
|
Box Dimensions (LxWxH) |
9.1 x 5.9 x 3.3" |
Tilta Quick Release Top Handle For BMPCC 4K Cage (Tilta Gray) Specs
|
Item Type |
Topside Handle with Cheeseplate-Style Handle |
|
Rotation |
No |
Mounting
|
Attachment Method |
Attaches via 1 x Built-In Screw (Unspecified Type) |
|
Compatibility |
Attaches onto Camcorder Support for: |
|
Rod Standard |
15 mm Single Rod |
|
Rod Ports |
1 x 15 mm Rod Port |
|
Accessory Mounting |
Multiple x 1/4"-20 Thread |
|
Shoe Mounting |
2 x Built-In Cold Shoe Slot |
|
Rosettes |
None |
|
Rail Mounting |
None |
General
|
Materials |
Aluminum, Steel |
|
Dimensions |
5.6 x 2.8 x 0.8" / 14.3 x 7.1 x 1.9 cm |
|
Weight |
6.1 oz / 172.8 g |
Packaging Info
|
Package Weight |
0.5 lb |
|
Box Dimensions (LxWxH) |
7.1 x 4.2 x 1.8" |
Tilta HDMI Cable Clamp Attachment For Sony A7 And A9 Cage (Tilta Gray) Specs
General
|
Material of Construction |
Aluminum, Stainless Steel |
|
Dimensions |
4 x 3.5 x 3" / 10.2 x 8.9 x 7.6 cm |
|
Weight |
1.36 oz / 39 g |
Packaging Info
|
Package Weight |
0.05 lb |
|
Box Dimensions (LxWxH) |
12.1 x 4.25 x 0.75" |
Tilta HDMI-01-M HDMI To Micro-HDMI Adapter Specs
General
|
Connector 1 |
1 x HDMI Female |
|
Connector 2 |
1 x Micro-HDMI Male |
|
Conductor Material |
Copper |
Packaging Info
|
Package Weight |
0.045 lb |
|
Box Dimensions (LxWxH) |
6.6 x 4.25 x 0.95" |
Tiltaing Side Focus Handle Type III (NP-F570, Tilta Gray) Specs
Mounting
|
Attachment Method |
Attaches via 1 x Built-In Screw (Unspecified Type) |
|
Compatibility |
Attaches onto DSLR/Mirrorless Support for: |
|
Accessory Mounting |
None |
|
Shoe Mounting |
None |
|
Rosettes |
None |
|
Rail Mounting |
None |
General
|
Item Type |
Left-Side Handgrip |
|
Rotation |
No |
|
Built-In Controls |
Remote Trigger, Focus Control |
|
Battery |
1 x Sony L-Series Battery (Not Included) |
|
Inputs/Outputs |
1 x Micro-USB (8 VDC) |
|
Materials |
Aluminum, Steel |
Packaging Info
|
Package Weight |
0.65 lb |
|
Box Dimensions (LxWxH) |
6.8 x 4.5 x 4" |
