Neumann KH 120 A G

by Neumann
Verfügbarkeit: 7-10 days delivery
SKU
SEN-503930

5.25" Composite Sandwich Woofer Cone, 1" Titanium Dome Tweeter, 160 W Peak Analog AB Amplifier, Elliptical Modeled Dispersion Waveguide

726,75 € 581,40 €

Paket beinhaltet

  • 1 x Neumann KH 120-A Studio Monitor
  • 2 x Main Cables (European and US Version)
  • 4 x Self-Adhesive Feet

The Neumann KH 120-A Studio Monitor combines a 1" titanium fabric dome tweeter powered by 50 W RMS (80 W peak) of analog amplification with a 5.25" long throw composite sandwich cone bass driver powered by 50 W RMS 80 W peak) analog amplification with dual front panel bass ports. The two speaker drivers are mounted in an elliptical mathematically modeled dispersion waveguide for smoother off-axis response and a more forgiving sound signature in different acoustical environments.

The front panel is made from one piece without discontinuities to reduce diffraction with protective metal grills and the cabinet is made of magnetically shielded aluminum to reduce resonances, improve heat dissipation, and extend the operating lifetime of the unit. The monitor is suitable for professional tracking, mixing, and mastering applications in broadcast, project, and post-production studios.

The system delivers a free field frequency response of 52 to 21,000 Hz with 4-position bass, low-mid, and treble acoustical controls for tailoring the response to different rooms and an input gain control from 0 to -15 dB. The front panel Neumann logo functions as an LED indicator for power and clip/limiting but can also be dimmed for light applications and for use when placed behind screens. A variety of wall, ceiling, truss, subwoofer, stand, and surface mounting options are available through a range of accessories (sold separately).

Titanium Fabric Dome
Provides low-distortion high-frequency reproduction
Elliptical Mathematically Modeled Dispersion Waveguide
Provides smoother off-axis response for more forgiving and diverse acoustic environments
Composite Sandwich Cone
Provides Damping of break-up modes
Long Throw Bass Driver
Enables low distortion at high sound levels
Two-Color + Dimmable Neumann Logo
Displays operation status and activation of the extensive protection system
Metal Grill
Protects against mechanical damage
Large Front Panel Ports
Reduces bass compression and makes it easier to mount in tight spaces such as OB vans
Compact Magnetically Shielded Aluminum Cabinet
Minimizes resonances and provides better heat dissipation for a longer product life
Wide Horizontal Dispersion
Provides freedom of movement across the mixing console
Narrow Vertical Dispersion
Reduces reflections off the mixing console
One-Piece Front Panel Without Discontinuities
Reduces diffraction and smoother frequency response
Powerful Analog Amplifiers With Ample Headroom
Improves transient response
Production Consistency
Ensures matched pairs
4-Position Bass, Low-Mid and Treble Acoustic Controls
Enables more control in diverse acoustical environments
Wide Range of Input Gain and Output Level Controls
Enables easier interfacing with signal sources
New Mounting Hardware Options
Offers flexibility in mounting cabinets in more diverse locations
Display Dimmer
Allows adjustments for low lighting conditions or behind the screen applications
Ground Lift
Reduces noise in electrically noisy environments and over comes ground loops
Universal Switched-Mode Power Supply (100 to 240 V)
Allows for one version to work in any country and with poor quality main power supplies
Separate Woofer and Tweeter Electronic Limiters and Thermal Protection Circuitry
Ensures long-term reliability
Frequency Response Free Field: 52 to 21,000 Hz ±3 dB
Pass Band Free Field: 54 to 20,000 Hz ±2 dB
Self Noise < 20 dB(A) at 10 cm
Total Harmonic Distortion (THD) > 100 Hz (<0.5% at 96 dB SPL at 1 m)
Max SPL Level Full Space: 105.1 dB
Half Space at 3% THD at 1 M: 111.1 dB

Short Term SPL with IEC-Weighted Noise: 107 dB(C)
With Music Material at 2.3 m (pair): 97 dB(C) (full range), 104 dB(C) (with subwoofer)

Long Term SPL with Pink Noise at 2.3 M, In Typical Listening Conditions (single/pair): 88/93 dB(C) SPL (full range, 89/94 dB(C) SPL (with subwoofer)
Bass Capability 104.8 dB
Electronics
Amplifier Woofer: 50 W (80 W peak)
Tweeter: 50 W (80 W peak)
Controller Design Analog, active
Crossover Frequency 2,000 Hz
Crossover Slope 24 dB/octave, 4th order
Equalization Bass: 0, -2.5, -5. -7.5 dB
Mid: 0, -1.5, -3, -4.5 dB
High: +1, 0, -1, -2 dB
Protection Circuits Limiter, low, high
Infrasonic filter protection 30 Hz; 6 dB/octave
Impedance 10 k Ohms in position 94/108 dB SPL at 1 m
20 k Ohms in position 100/114 dB SPL at 1 m
Input Gain Control 0 to -15 dB
Output Level Control 94, 100, 108, 114 dB
CMRR >56 dB at 15,000 Hz
Maximum Input Level 24 dBu
Indicators Power On: Neumann logo "white"
Limit/Clip: Neumann logo "red"
Power Supply 100 to 240 V; 50/60 Hz
Power Consumption Idle: 20 W
Full Output AC: 200 W
Mechanical
Cabinet Painted aluminum, anthracite (RAL 7021)
Powder-coated aluminum, white (RAL 9016)
Operating Conditions +50 to +104° F (+10 to +40° C)
<90% relative humidity, non-condensing
Drivers Magnetically Shielded
Woofer: 5.25" (130 mm)
Tweeter: 1.00" (25.0 mm)
Mounting 2x M8 on rear panel
Volume Internal: 6.5 liters
External: 9.7 liters
Dimensions (H x W x D) 10.875 x 7.125 x 8.625 (277.0 x 182.0 x 220.0 mm)
Weight 14.1 lb (6.40 kg)
